Multi-Band Transceiver System Revision 0

Installation MN/MBT4000B.IOM

2-4

2.2.4 AUX COMM 1 (J9) PIN CONNECTIONS

Table 2-5. Aux Comm 1 (J9) Pin Connections

Pin AUX COMM1 (J9)

A AUX Rx + A

B AUX Rx – A

C AUX Tx + A

D AUX Tx – A

E +12.6V LNA A

F IO1 A/Fault see Note 1

G IO1 B see Note 2

H GND

Mating Connectors:

Cannon MS3116J12-8P

CN/MS3116J12-8P

Notes:

1. Input from external amplifier.

2. Normally, an Input, when programmed as an output, this pin indicates

Online/Offline status of Unit 1.
